Product Dimensions 7.63"h x 17.5"w x 19.13"d
1.5 kVA encapsulated toroid power transformer with independent secondary windings for each channel. Complementary MOSFET driver stage and JFET input stage. Auto turn-on by 12v trigger or audio signal.Read More
250 watts x 3 @ 8 Ohms / 400 watts x 3 @ 4 Ohms
Adjustable gain for up to +6db over THX Reference level
Unbalanced RCA and balanced XLR inputs
Circuitry designed by legendary John Curl
High bias class A/AB operation
Direct coupled (no capacitors or inductors in signal path)
Complementary MOSFET driver stage and JFET input stage
24 beta-matched 15 amp, 60 MHz bipolar output transistors
1.5 kVA encapsulated toroid power transformer with independent secondary windings for each channel
98,400 µF power supply filter capacitance
DC Servo and relay protection circuits
AC present, channel status, high temperature indicators
Heavy-duty 24k gold-plated 5-way speaker terminals
THX Ultra2 certified
Auto turn-on by 12v trigger or audio signal
4u Chassis, carry handles, rack mounting adapter included
General Specs | |
| Depth (in.) | 19.13 |
| Height (in.) | 7.63 |
| Impedance | 94 k Ohms |
| Width (in.) | 17.5 |
| Analog Audio(RCA) Input | 3 |
| Color Finish Name | Black |
| Product Weight (lbs.) | 65 |
| Color | Black |
Specifications | |
| Signal to Noise Ratio: | 112 dB |
| Watts RMS per Channel (4-ohms): | 400 |
| Watts RMS per Channel (8-ohms): | 250 |
Styling | |
| Color: | Black |
